WIRING DIAGRAM
REF# PART# DESCRIPTION QUANTITY
1 12-017 Hour Meter 1
2 50-360 Fuse Holder 1
22-071 Fuse 30 AMP 1
3 13-050 Purple Wire (fuse to ammeter) 1
4 After Fire Solenoid (on engine) 1
5 Rectifier (on engine) 1
6 22-003 Ammeter 1
7 Stop Switch Terminal (on engine) 1
8 22-054 Battery Cable, Black 1
9 Battery, automotive type 45-12V; 480 cold cranking
AMPS minimum
(5 3 /
8
" wide x 9" high x 9" long) 1
10 22-055 Battery Cable, Red 1
12-031 Battery Boot (comes with red battery cable) 1
11 13-492 Solenoid (B & S# 807829) 1
12 13-215 Starter Cable 1
13 Starter (on engine) 1
14 50-359 Oil Pressure Light 1
15 8862 Coupler 1
16 22-002 Interlock Switch 1
17 13-488 Ignition Switch (B & S# 496603) 1
18 13-491 Oil Sender (on engine) (B & S# 491657) 1
19 13-641 Red Wire (ignition to hour meter) 1
22-017 Ground Cable from Engine to Solenoid Mount 1
* 13-497 Wire Harness
