Accessories
13-577 SCARIFIER VERTICAL BLADES PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 13-578 Frame 1
2 HNTL-716-14 Lock Nut 7 /
16
-14 2
3 HB-716-14-150 Bolt 7 /
16
-14 x 1 1 /
2
2
4 13-146 Attachment Lift (part of Lift Assembly) 1
5 HMB-34-10 Machine Bushing 3 /
4
x 10GA 12
6 HRP-14-100 Roll Pin 1 /
4
x 1 2
7 HN-38-16 Nut 3 /
8
- 16 10
8 HWL-38 Lockwasher 3 /
8
10
9 26-042 Tine Segment 5
10 HB-38-16-100 Bolt 3 /
8
- 16 x 1 10
11 13-115 Hitch (Pistols) 2
12 HCP-12-150 Clevis Pin 1 /
2
x 1 1 /
2
2
13 HHP-18 Bridge Pin 1 /
8
3
14 13-117 Grader Blade 1
15 19-217 Hook 1
16 HMB-12-14 Machine Bushing 1 /
2
x 14GA 4
17 HP-18-100 Cotter Pin 1 /
8
x 1 2
INSTALLATION INSTRUCTIONS
Optional Lift Assembly 13-505 must be installed before installing this unit on Super 2
1. Bolt five tine segments (Ref 9) to frame (Ref 1) using ten bolts, lockwashers and nuts (Ref 7, 8 and 10) as
shown on drawing.
2. Put hook (Ref 15) over right hand tube on frame (Ref 1). Hook is to used to hold grader blade up when not
in use.
3. Insert hitch (pistols) (Ref 11) into tubes of main frame with up to five machine bushings (Ref# 5) in front
and one bushing in rear of the tube. Secure pistols with roll pins (Ref# 6). Check the spacing before driving
roll pin in all the way. For more tire clearance, machine bushings may be moved from front to rear.
4. Put the grader blade (Ref 14) on as shown using two bridge pins (Ref 13).
5. Lift up frame (Ref 1) and hook pockets over the arms of attachment lift (Ref 4).
6. Attach pistols to the tabs of the trap rake frame undercarriage in the rear holes using clevis pins (Ref 12)
and bridge pins (Ref 13).
7. Turn machine on and test for proper operation.
