SIERRA VIDEO SYSTEMS
60
Digital Video
Data rates 19-360 Mbps
Data types SMPTE 259, SMPTE 310, DVB-ASI
Input cable equalization range 0 – 200 meters
Input return loss >15db
Output level 750 – 850 mVp-p
Output jitter < 0.2 UI
Output return loss >15db
I/O connectors 75 Ohm BNC
Re-Clocking Yes
Control Port Specifications
Control Panel Port (Port 1) RS-485
Total Number of Panels Supported Up to 100
Cable Type 2-wire shielded (Belden 8451 or equivalent
Maximum Cable Length 5,000 ft. (1,500 m)
Terminal Port (Port 2) RS-232C
Data Rates 1.2 Kbps, 2.4 Kbps, 9.6 Kbps, or 19.2 Kbps
Host Port (Port 3) RS-232C (RS-422 optional)
Data Rates 1.2 Kbps, 9.6 Kbps, 38.4 Kbps, or 115.2 Kbps
Mechanical & Operational Characteristics
Frame Height 3, 4, or 9 RU depending on model
Frame Depth 16” (41 cm)
Operating Temperature Range 0 – 40 degrees C
Input Voltage 115 VAC or 230 VAC +/- 10% (switch
selectable)
Power Requirements 80 – 200 VA
Weight 3 RU, 35 lbs (15.9 kg); 4 RU, 45 lbs
(20.5 kg); 9 RU, 70 lbs (31.8 kg)
