Technical Specifications
Table 4. Card - Technical Specifications
Category Parameter Specification
Serial Digital
Video Input
Data Rates Supported
SMPTE 292 HD-SDI:
1.485 Gbps or 1.485/1.001 Gbps
SMPTE 259M-C SD-SDI:
270 Mbps
Frame Rates Supported
HD:
720p 23.98/24/25/29.97/30/50/59.94
1080i 25/29.97
1080p 23.98/24/25/29.97/30
1080p/sF 23.98/24
SD:
486i 29.97 NTSC, 575i 25 PAL
Impedance 75

terminating
Equalization
HD: 328ft (100 meters) Belden 1694A
SD: 1000ft (300 meters) Belden 1694A
Return Loss >18dB at 5MHz - 1.485GHz
Category Parameter Specification
Serial Digital
Video Outputs
Number of Outputs 2:HD/SD-SDI BNC per IEC 60169-8 Amendment 2
Impedance 75

Return Loss > 15 dB at 5MHz – 270MHz
> 12 dB at 270MHz – 1.485GHz
Signal Level 800 mV ±10%
DC Offset 0 Volts ±50 mV
Jitter HD: < 0.15UI (all outputs)
SD: <0.06UI (all outputs)
Overshoot <0.2% of amplitude
