ROTEL RMB-1555 User Manual
Page 6
6
RMB-1555/RMB-1585 Five Channel Power Amplifiers
Figure 3:
Balanced (XLR) Inputs
Branchements des entrées symétriques (XLR)
Symmetrische (XLR) Eingänge
Entradas Balanceadas (XLR)
SURROUND RIGHT
SURROUND LEFT
FRONT RIGHT
FRONT LEFT
CENTER
MULTICHANNEL ANALOG OUTPUTS
REAR R
FRONT R
CENTER
FRONT L
REAR L
RMB-1585
Gebalanceerde ingangen (XLR)
Ingressi analogici bilanciati (XLR)
Balanserade ingångar (XLR)
Балансные (XLR) входы
