2.4 General notes
n It is necessary to lay a power supply cable both
to the outdoor unit and, separately, to the
indoor unit.
n Power to the indoor unit may not be discon-
nected by the power company if there is a dis-
able period circuit (anti-freeze protection).
n The indoor unit requires a single-phase power
supply of 230 V / 50 Hz.
The outdoor units if the WKF 180 Duo require
a three-phase power supply of 400 V / 50 Hz.
The WKF 120 Duo outdoor units required a
230 V / 50 Hz power supply
n The electrical connection between outdoor and
indoor units is made using a shielded three-
core control line.
n Where applicable, a separate power supply
shall be provided to the indoor unit for an auxil-
iary heater.
n The heat pump manager needs to know
whether a power-company enable or disable
period is in effect. A potential-free switch must
be provided by the customer for this purpose.
(A closed switch signifies an enable, an open
switch a disable period.)
n A connection schematic along with corre-
sponding circuit diagrams can be found in the
"Connection diagram" chapter of this manual.
n Special rates for heat pumps may be offered
by the power company.
n Ask your local power company about the
details of any rates that might be available.
DANGER!
All electrical installation work must be done by
an electrician.
WARNING!
Always note the currently applicable VDE
guidelines and the notes in TAB 2007. The size
and type of the fuse are to be taken from the
technical data.
WARNING!
All cable sizes are to be selected according to
VDE 0100. Special attention should be given to
cable lengths, cable type and the kind of instal-
lation. The information in the connection dia-
gram and in the system overview are to be
seen as an acceptable installation possibility
only in a standard case!
NOTICE!
Make sure to connect the outdoor unit neutral
connector properly, otherwise the varistors on
the line-filter circuit board will be destroyed.
NOTICE!
The electrical connection for the units must be
made at a separate feedpoint with a residual
current device in accordance with local regula-
tions and should be laid out by an electrician.
Check all plugged and clamped terminals to
verify that they are seated correctly and make
permanent contact. Tighten as required.
