List of spare parts PG 25
Fig.-No. Description EDV-No.
1 transport handle 1101142
2 outside casing 1101381
3 combustion chamber 1101384
4 end plate, front 1101382
5 blow out protection grille 1101383
6 safety thermostat with sensitive element 1101197
7 inspection cover 1101385
8 terminal strip, 6er 1101366
9 thermocouple 1101164
10 ignition cable 1101283
11 ignition electrode 1101180
12 angled screw coupling 1/8" x 6 mm 1101316
13 gas nozzle 1101159
14 gas pipe R/Z 1101451
15 gas pipe Z/D 1101452
16 piezo igniter 1101364
17 tube fitting M10 x 1 1101409
18 gas regulator 1101411
19 thermoelectic gas valve 1101169
20 angled coupling 1/8" x 6 mm 1101468
22 gas pipe M/R 1101441
25 GE - coupling 1/4" x 6 mm 1101396
26 solenoid valve 1101376
27 gas connection nipple 3/8", left handed thread 1101134
28 control knob, cpl. 1101192
29 operating switch, cpl. 1101188
30 traction relief 1101267
31 connecting cable with plug 1101320
32 end plate, rear 1101415
33 fan motor 1108049
34 clutch plate B 6 Ø 1108455
34 clutch plate B 7 Ø 1108014
35 fan blade 1101392
36 clutch disc 1101375
37 gas burner 1101417
38 protection socket 1101304
39 retaining bracket 1101395
not shown: pressure controller with hose-break protection 1101470
2 running metres gas hose 1101369
2 running metres HD-gas hose 1101174
multi-cylinder set (2 - 3 cylinders) 1014050
T - connection for multi-cylinder set 1101177
nylon seal for T - connection 1101178
HD - gas hose 0,4m for multi-cylinder set 1101179
W h e n o r d e r i n g s p a r e p a r t s i t i s n e c e s s a r y t o i n d i c a t e
E D V - N o . a n d m a c h i n e n o . ( s e e d a t a p l a t e ) !
