Electric shock can cause INJURY or DEATH.
IMPORTANT- Disconnect all electrical power to the welding power source and wire feeder before
attempting installation of this unit.
® Your PROFAX HD450 Amp AMT Machine Torch comes standard with a Tweco style rear connector. Adapter Kits for most
domestic style feeders as well as a Euro-Quick connector for European style feeders are also available. Please note that non
GMA wire feeders will require a gas solenoid valve.
INSTALLATION
1.) Make sure that the gun is equipped with the proper contact tip and conduit for the type and size of wire to be used before
installation.
2.) Make sure that the adapter, the feeder outgoing guide, and the drive rolls are correct for the type and size of wire to be
used.
3.) Lay the PROFAX AMT Machine Torch out in a straight line.
4.) Push the brass connector end of the gun cable into the brass adapter on the outgoing side of feeder wire drive until it is
fully seated. Secure the cable with the set or hand screw in the adapter.
5.) Remove the nozzle and contact tip from the AMT Machine Torch.
6.) Relieve tension and disengage drive rolls. Feed wire by hand through drive rolls, outgoing guide and adapter plug until
wire is at least one too two feet inside of PROFAX AMT Machine Torch.
7.) Reset drive rolls and apply proper tension. Keep gun in a straight position. Continue to feed wire through the gun by
using the inch button on the feeder.
8.) Install the nozzle and contact tip back onto the AMT Machine Torch.
9.) When you activate the feeder, the contact tip and welding wire protruding from tip are electrically “HOT”. Set the power
source to the proper settings for wire size and welding application to be used. Make sure the shielding gas supply is
adjusted to the proper flow rate. Gun is now ready for operation.
GUIDELINES TO AVOID WIRE FEEDING PROBLEMS AND
TO KEEP YOUR MACHINE TORCH OPERATING SMOOTHLY
1.) Use only good quality welding wires that are clean and rust free.
2.) Keep the cable assembly as straight as possible, and do not kink or pull cable around sharp corners or allow carts or
trucks to run over the cable assembly.
3.) Make sure the contact tip is tightly screwed into the gas diffuser at all times. Frequently clean the contact tip and nozzle.
The use of a good anti-spatter compound will increase tip and nozzle life and will make spatter removal easier. If the
contact tip becomes deformed, arced or worn at the end, replace it immediately.
4.)On a regular basis, check all gun, cable and gas hose connections. Make sure they are clean and tight.
BY FOLLOWING THESE SIMPLE GUIDELINES YOU WILL
EXTEND THE LIFE OF YOUR PROFAX AMT MACHINE TORCH.
®
