Desa CGMFP - Manual (Page 31)

www.desatech.com 119315-01A 31
KEY
NO.
PART NO. DESCRIPTION QTY
1 118596-01 Top Panel • • 1
11853-01CK Top Trim Panel • • 1
3 11854-01 Heat Deflector • • 1
4 11856-01CK Screen Assembly • • 1
5 1185-01CK Access Door • • 1
6 11858-01CK Side Panel Trim • •
** Firebox Floor • • 1
8 ** Bottom Panel • • 1
9 ** Fireplace Wrapper • • 1
10 118941-01 Rear Brick Liner • • 1
11 118941-0 Left Brick Liner • • 1
1 118941-03 Right Brick Liner • • 1
13 118941-04 Top Liner • • 1
14 119310-01 Burner • • 1
15 103158-01 Magnetic Catch • •
16 11860-01 Magnetic Catch Bracket • •
1 10089-01 Control Valve • • 1
18 11091-0 Manual Valve Bracket • • 1
19 108480-01 Knob • • 1
0 098508-01 Valve Retainer Nut • • 1
1 099415-10 Gas Regulator • • 1
118-01 Outlet Tube • • 1
3 1186-01 Inlet Tube • • 1
4 118606-01 Ignitor Bracket • • 1
5 09159-04 Piezo Ignitor • • 1
6 0981-1 Ignitor Cable • • 1
10486-01 ODS Pilot, Propane/LP Gas • 1
10485-01 ODS Pilot, Natural Gas • 1
8 11945-03 Injector, NG • 1
11945-01 Injector, LP • 1
9 09938-08 Pilot Tube • • 1
30 11881-03 Pilot Shield • • 1
31 09809-03 Male Fitting • • 1
3 09930-0 Screw, HWH Shoulder AB 10 X .63 • • 4
33 098303-0 Screw, SHWH AB 6-0 x .31 • •
34 M1583- Screw, PHWH B 10-16 x .50 • • 13
35 M1461-6 Screw, Hex SLT WSR 1/4-0 x .38 • • 1
36 1084-01 Knob for Access Door • • 1
3 118938-01 Log Set • • 1
38 M11084-38 Screw #8-18 x 3/8 • • 1
39 11855-01CK Firebox Hood • • 1
40 101386-0 Hinge • •
41 098304-01 Screw, PPH AB 10-16 X .38 • • 44
4 10169-0 Bushing • • 1
43 10168-04 Flexible Connector • • 1
PARTS AVAILAbLE - NOT SHOWN
901056-01 Brass Flare Fitting • • 1
101480-1 Jumper Wire • • 1
10340-01 Hardware Pack • • 1
101055-0 Lighting Instructions Plate • • 1
paRTs lisT
MANUAL-CONTROLLED MODELS
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 29 of this manual.
CGMFN CGMFP
**Not a field replaceable part.
