1.4.2 TCP/IP
MODBUS TCP, 10Base T output connections are made as shown. Requires 10Base T cable
and Rj45 connector.
!
CAUTION
Only qualified service personnel should make connections between the System-10 BTU Meter
and the user’s external equipment. ONICON assumes no responsibility for damage caused to
the external equipment as a result of an improper installation.
NOTE: RJ45 Connector
MODBUS TCP
MODBUS TCP
