SM28 Rev. 4.10 NTX VHF-FM Series Remote Mount Transceivers Manual
2.3.8
Post-Installation EMI Test
The purpose of this test is to identify any interference that the transceiver may cause
with existing aircraft systems. The transceiver should be tested in accordance with the
Installation Approval Test Procedure (see section 2.5) and the test results documented
on the record sheets.
2.4 Continued Airworthiness
Maintenance of the NTX VHF-FM Series Remote Mount Transceiver is ‘on condition’
only. Periodic maintenance of these products is not required.
2.5 Installation Drawings
DRAWING REV.
DESCRIPTION TYPE
NTX138\403-0 1.22 Remote Mount Radio Interconnect
NTX138\405-0 1.00 Remote Mount Radio Connector Map
NTX138\922-0 1.02 Remote Mount Radio Mechanical
NTX-VT1\922-0 1.00 Vertical Mount Tray Mechanical
NTX138\634-0 1.00 Post-Installation EMI Test Installation Approval Test Procedure
NTX066\634-0 1.00 Post-Installation EMI Test Installation Approval Test Procedure
Section 2 ends after these Drawings
Jun 1, 2004 Page 2-5
