NTX VHF-FM Series Remote Mount Transceivers Manual SM28 Rev. 4. 10
1.4.4 Physical
Specifications
Height 2.21" (56.1 mm)
Overall
length 11.38"(289.1 mm)
Length without connector 10.67” (271.1 mm)
Width
5.23" (271.2 mm)
Weight 4.0
lbs (1.8 kg)
Mounting Custom NAT ¼ ATR tray mount (NTX-VT1)
Connector type Male filtered 25-pin D-subminiature with Positronics
V5 locking tabs
Antenna connector Bulkhead female BNC
1.4.5 Environmental
Specifications
Temperature -30 ° C to +60° C
Altitude 25,000
feet
Humidity
95 %
Shock 12 g (any axis)
Environmental
conformance:
DO-160C Env. Cat. B4-BA[MN]XXXXXXAB[AB]BAUAXXX
1.5 VHF-FM Radio Spurious Frequencies
All VHF-FM radios are subject to the reception of spurious signals. Avoid operation on
these frequencies whenever possible.
The frequencies affected within the NTX066 radio are 66.00 MHz, 72.00 MHz, and
84.00 MHz.
The frequencies affected within the NTX138 radios are 138.000 MHz, 144.000 MHz,
156.000 MHz and 168.000 MHz.
Page 1-4 Jun 1, 2004
