SM28 Rev. 4.10 NTX VHF-FM Series Remote Mount Transceivers Manual
1.4.2 Receiver
Channel increments 2.5 kHz
Audio output
NTX066 and NTX138 models 100 mW into 600 Ω, nominal
Sensitivity
NTX066-000
0.50 µV @ 12 dB SINAD
NTX138-050 Main 0.50 µV @ 12 dB SINAD
Guard 0.50 µV @ 12 dB SINAD
NTX138-000 0.35 µV @ 12 dB SINAD
NTX138-100 Main 0.35 µV @ 12 dB SINAD
DF 1.0 µV @ 12 dB SINAD
Selectivity
-70 dB min. @ 25 kHz (Wideband)
-60 dB min. @ 12.5 kHz (Narrowband)
Spurious response
-70 dB
Intermodulation
-70 dB
1.4.3 Transmitter
RF power output 1 W/10 W selectable
RF output impedance
50 Ω nominal
Modulation
Wide
band ±5.0 kHz max., limited
Narrow band ±2.5 kHz max., limited
Output spurious -65 dB
Frequency stability ±0.0003 %
FM noise -45 dB
Distortion <5% nominal, 10% max.
