Delta Electronics SMT Power Inductor SIC73 User Manual

Smt power inductor, Sic73 type, Features

background image

o

At 25 C: 1KHz, 1V

SMT Power Inductor

SIC73 Type

RoHS compliant.
Low profile (2.5mm max. height) SMD type.
Magnetically shielded,suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter,
DC-AC inverters inductor application.
In addition to the standard versions shown here,
customized inductors are available to meet your exact requirements.

Features

64

Electrical Characteristics:

0.00

0.01

0.10

1.00

10.00

CURRENT (A)

1.00

10.00

100.00

1000.00

10000.00

IN

D

U

C

T

A

N

C

E

(u

H

)

100

120

150

180

220

270

330

470

560

680

820

101

390

121

151

181

221

271

331

391

471

561

681

821

102

122

152

182

222

272

332

392

SIC73-100

10

0.200

0.700

SIC73-120

12

0.220

0.616

SIC73-150

15

0.291

0.572

SIC73-180

18

0.307

0.524

SIC73-220

22

0.355

0.468

SIC73-270

27

0.412

0.432

SIC73-330

33

0.456

0.392

SIC73-390

39

0.580

0.372

SIC73-470

47

0.671

0.340

SIC73-560

56

0.735

0.284

SIC73-680

68

0.981

0.276

SIC73-820

82

1.110

0.256

SIC73-101

100

1.250

0.228

SIC73-121

120

1.400

0.208

SIC73-151

150

1.850

0.188

SIC73-181

180

2.110

0.168

SIC73-221

220

2.540

0.160

SIC73-271

270

4.130

0.144

SIC73-331

330

4.350

0.128

SIC73-391

390

4.860

0.120

SIC73-471

470

6.640

0.104

SIC73-561

560

7.250

0.096

SIC73-681

680

8.180

0.088

SIC73-821

820

9.680

0.080

SIC73-102

1000

15.400

0.072

SIC73-122

1200

18.100

0.070

SIC73-152

1500

18.800

0.064

SIC73-182

1800

20.600

0.055

SIC73-222

2200

32.300

0.050

SIC73-272

2700

36.800

0.046

SIC73-332

3300

40.900

0.040

SIC73-392

3900

48.800

0.037

D

E

A

B

H

2

3

G

1

4

F

2.9

2.3

1.6

1.7

Mechanical Dimension:

UNIT:mm/inch
A = 7.5 0.5 / 0.295 0.020
B = 6.8 0.5 / 0.268 0.020
C = 2.5 / 0.098 Max.
D = 0.7 / 0.028
E = 1.2 / 0.047
F = 0.7 / 0.028
G = 2.8 / 0.110
H = 2.0 / 0.079

C

RECOMMENDED PAD PATTERNS

2

Irated

(Adc)

PART NO.

1

L

(uH)

DCR

( ) MAX

1. Tolerance of inductance: 30% for 10~82uH, 20% for 100~820uH, 10% for 1000~3900uH.
2. Irated is the DC current which cause the inductance drop 10% typical of its nominal inductance without current
and the surface temperature of the part increase less than 45
3. Operating temperature : -20

to 105

(including self-temperature rise).

o

C.

o

o

C

C

DELTA ELECTRONICS, INC.

(TAOYUAN PLANT CPBG)

252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
