15
Pin Assignments of PC IN
2 TxD (PC)
3 RxD (PC)
7 Ground
20 DTR (PC)
Pin Assignments of RELAY
1 REL1a on
2 REL1a com
3 REL1a off
4 REL1b on
5 REL1b com
6 REL1b off
Rear Panel Connectors
Name Type Signal Cable
PC IN 25pin SUB-D RS232 shielded data line
RELAY 9pin SUB-D
IN 25pin SUB-D RS232 shielded data line
OUT 25pin SUB-D RS232 shielded data line
Ant. BNC 77.5kHz shielded coaxial line
Power power cord receptacle 85-264VAC / power supply cord
120-375VDC
CE Label
This device conforms to the directive 89/336/EWG on the
approximation of the laws of the Member States of the European
Community relating to electromagnetc compatibility.
