3
ME NU
SE LE CT
LA MP STA TU S PO WE R
ON/S TAND BY
SO UR CE
AUTO ADJ.
E N TE R
EX IT
FO C U S
ZO O M
1. Introduction
ᕣ Part Names of the Projector
Front/Top
FO CU S
ME NU
SEL ECT LAM P STA TUS POW ER
ON/S TAN D B Y SOU RCE AUT O A DJ.
E N T E R
E X I T
ZO OM
Digital Zoom Button)
( → page 24 )
Controls
(
→ page 5 )
Lens
Lens Cap
Built-in Security Slot ( )*
Focus Ring
( → page 24 )
Remote sensor
( → page 8 )
Ventilation (inlet) / Filter Cover
(
→ page 50 )
Two filters
AC Input
Connect the supplied power cable's two-pin plug here, and
plug the other end into an active wall outlet. (
→ page 19 )
Main Power Switch
When you plug the supplied power cable into an active wall outlet
and turn on the Main Power, the POWER indicator turns orange
and the projector is in standby mode.
(
→ page 20 , 28 )
Remote sensor
(
→ page 8 )
Terminal Panel
( → page 6 )
Monaural Speaker
(5W)
* This security slot supports the MicroSaver ® Security System. MicroSaver ® is a registered trademark of
Kensington Microware Inc. The logo is trademarked and owned by Kensington Microware Inc.
Ventilation (outlet)
Heated air is exhausted from here.
Rear
FO CU S
ZO OM
Zoom lever
