User Manual ES8000
25
Replacing InFeed Roller Set
Maintenance
Exchanging Friction Reverse Roller
The feeding rollers consist of three different rollers.
1. Pickup Roller
2. Feed Roller
3. Separate Roller
It depends on the paper weight, type and etc., but please check the parts and
change when you produce over 100,000 products, if necessary. How to change
the parts are as follows.
Feed Roller Separate Roller
(Below Feed Roller)
Pickup Roller
1. Remove the snap ring (white clip).
2. Replace the roller and place back the snap ring.
3. Follow step 1 & 2 for the rest of the rollers.
