Mathey Dearman MagnaCut XM - Manual (Page 5)

5
Section 3 – Technical Diagrams Cont…
Description MagnaCut
Method of Attachment to
Pipe or Plate
Rare Earth Magnets
Magnetic Pull per Wheel Assembly. 150lbs. / 68kg
Polyurethane, Carbon Zinc or
Epoxy Coatings Up to 15mils or .015 /
.4mm thick
Set-Up Time 2 Minutes
Cutting Range Pipe O.D. 6 5/8” (168.3) and Up
Cutting Range Pipe I.D. 24” (609.5mm) and Up
Vertical Cutting Capability Pipe or Plate
Horizontal Cutting Capability Pipe or Plate
Diagonal Cutting Capability Plate Only
Miter or Saddle Cutting Capability Shallow Miters or Saddles Only
Minimum Speed 2” (51mm) per min.
Maximum Speed 40” (1016mm) per min.
Net Weight 37lbs (16.7kg)
Shipping Weight 60lbs (27kg)
Shipping Dimensions 20” x 9” x 25” / 508 x 229 x 635
Machine Dimensions
Width (Torch Arm Extended) 17” (432mm)
Length 14” (356mm)
Height 5 ¼” (133mm)
Electrical Requirement
115vac or 230vac 50/60Hz
(With Transformer)
