20
DC Circuit of Motor
Control Box is not
constant.
Torch improperly
adjusted. to Mathey Dearman.
The MagnaCut XM
is moving up and
down as it moves
along the pipe or
plate causing a
rough-cut.
Slag and other debris
are on the Drive
Wheels and/or pipe. Remove debris from Wheels
and Pipe with Brass Brush
provided.
The Torch is
producing a rough
finish. Unit Speed Control
Rheostat (G) is
improperly adjusted. Adjust the Unit Speed Control
up or down until the desired
quality of cut is achieved.
Torch Cutting Tip is
dirty. Clean or replace the Torch
Cutting Tip.
Torch Improperly
adjusted Set the Torch Manufacturer’s
Operating Instruction for the
Cutting Torch.
