Mathey Dearman MagnaCut XM - Manual (Page 19)

19
Drive Motor (1)
overheats.
Unit is carrying
larger amount of
weight than it is
designed to carry. Replace with a 12” Machine
Torch. (Weight not to exceed
10lbs.
Transmission Helical
Gear and Wheel
Drive Gears are
binding. Return the MagnaCut XM to
Mathey Dearman for
adjustment.
Wheel Mounting
Blocks (Q) are out of
adjustment. Return the MagnaCut XM to
Mathey Dearman for
adjustment.
Torch is closer at
the top of the pipe
than it is at the
bottom of the pipe. Set Screw (26) is
loose in Torch
Support. Tighten Set Screw (16) in
Torch Support. (Refer to Page
6.)
Torch Arm (B) is out
of adjustment. Adjust play in Torch Arm, see
procedure: “Adjustment of the
Play in the Torch Arm
Assembly”.
MagnaCut XM is
not cutting square. Machine is dragging
Oxygen and Fuel
Hoses Wrap the Oxygen and Fuel
Hoses at least one full turn
around the pipe.
Wheel Mount Blocks
(Q) are out of
adjustment. Return the MagnaCut XM to
Mathey Dearman for
adjustment.
Unit is carrying
larger amount of
weight than it is
designed to carry.
Replace with a 12” Machine
Torch. (Weight not to exceed
10 lbs.).
Slag and other debris
on the Drive Wheel.
(D) Remove debris from Wheels
and Pipe with Brass brush
provided.
Torch Arm moves
in or out
intermittently. Damaged
Intermediate caused
by shock load. Replace Motor and avoid
shock load.
Input Motor Brushes
worn or not making
contact with
Commutator.
Replace Motor.
Worn Motor
Commutator.
Replace Motor Commutator. Check Motor connection and
replace if needed.
Output of 24 Volt
DC Circuit of Motor
Control Box is not
constant. Return the Motor Control Box
to Mathey Dearman for
evaluation.
Drive Motor works
intermittently. Damaged
Intermediate
damaged by shock
load.
Replace Drive Motor (1) and
avoid shock.
Input Motor Brushes
worn or not making
contact with
Commutator.
Replace Motor.
Worn Motor
Commutator.
Replace Motor.
Loose Motor
Commutator.
Check Motor Connection and
replace if needed.
Output of 24 Volt
Return the Motor Control Box
