14
Step 5: Check both Socket-Head Allen Screws (C) to ensure these are loose enough for the Machine Fuel Torch to slip
into the Torch Holder
Warning: Never use a cigarette lighter to light the cutting torch.
Step 6: Turn the Ratchet Handle (M) of the Torch Holder Assembly (8) counterclockwise and adjust the torch to the
desired bevel angle. Once the torch is set to the desired bevel angle, turn the Ratchet Handle clockwise to hold the
torch at that bevel angle.
Step 7: Adjust the Torch Tip to material distance per the Torch Manufacturer’s Operating Instructions.
Warning: The MagnaCut XM should not be used to back bevel pipe or plate. If enough heat is generated by the
cutting torch when back beveling, it will cause the Wheels of the MagnaCut XM to temporary loss magnetism
disengaging the machine from the pipe or plate.
Step 8: Preheat the material per the Torch Manufacturer’s Operating Instructions.
Step 9: Turn the Oxygen-Cutting Valve of the Fuel Torch to the cutting position to penetrate the material per the Torch
Manufacturer's Operating Instructions.
Step 10: Rotate the Torch Arm Rheostat (H) to the desired position.
Step 11: Move the Torch Arm In and Out Switch (F) in the direction required to move the torch to the cut line.
Note: The Torch Arm In and Out Switch (F) should be in the Stop Position for at least one (1) full second before
changing motor direction.
Step 18: To move machine in required direction - move the Forward and Reverse Switch (I) to the Forward or Reverse
position.
Note: The Forward and Reverse Switch (I) should be in the Stop Position for at least one (1) full second before
changing motor direction.
Step 19: Turn Drive Rheostat switch (G) to desired speed.
Note: Refer to the Manufacturer’s Oxygen Fuel Cutting Reference Chart for cutting trouble-shooting illustrations.
Shutting OFF the Machine after complete cut is made.
Step 1: Once the cut is complete, shut off the Oxygen-Cutting Valve of the Machine Fuel Torch per the torch
manufacturer’s instructions.
Note: Shut off the Oxygen-Cutting Valve as soon as possible to avoid under cutting the material.
Step 2: Turn off Oxygen and Fuel Valves of the Machine Fuel Torch per the torch Manufacturer’s instructions.
Step 3: Move the Forward /Reverse Switch (I) to the OFF or CENTER position.
Step 4: Move the Master Switch (N) to the OFF position
Step 5: Disconnect AC Power Cord (K) from the 115vac Power Source.
Step 5: Disconnect the DC Cord with Connector Plug (J) from the DC Connector Receptacle (L).
Step 6: Remove the Machine Fuel Torch (A) from the Torch Holder (8).
Step 7: The MagnaCut XM is now ready to be removed from the pipe. To remove MagnaCut XM from the pipe, grasp the
Cover Handle (10) and the Torch Block (6), and twist the machine while lifting upward. To remove MagnaCut
from the flat plate, grasp the cover handle and pull upward.
Note: Do not hold on to the Torch Arm (B) to disengage from pipe or plate.)
Step 8: Check the Gear Rack of the Torch Arm (B) after each cut for slag or other debris and remove it with the Brush
provided in the Storage Box.
Note: Do not use air to remove the slag or other debris from the Gear Rack of the Torch Arm as this may cause
the Torch Arm Motor not to function.
Section 10 - MagnaCut XM Maintenance and Repair
Warning: Before performing any maintenance on the MagnaCut XM, contact Mathey Dearman, Inc. Sales Department. The
disassembly of any part of the MagnaCut XM or adjustment of the components in MagnaCut XM Motor Control Box will
void the Machine’s Warranty.
