Serial Link
(recognized +
transmitted) MIDI-Byte Beschreibung
F0 (hex)
30
0n
18
01
DATA
CHECKS
F7 System Exclusive
DYNACORD ID: No 48
n = MIDI Channel 0 - 15 (7F = All Channels)
DSP 244 ID: No 24
Function ID: Serial Link / Parser
ASCII Code Line for Command Parser (up to 120
Byte)
Checksum for DATA (7 Bit, 2’s Complement)
End of SysEx Message
Further details concerning the Command Parser ASCII Code are shown in the following tables.
Device Commands
UNIT-ID Tree Value Unit
/ID1/
COMMAND/
STORE 1 ... 30
LOAD 1 ... 80
DUMP 0 ... 30
DEVICE ?
C o m P o r t C o n f i g u r a t i o n
Tree Value Unit
COMCONF
LINEFEED ON/OFF
PROMPT ON/OFF
ECHO ON/OFF
M I D I
10-3
