8.1.2 PARAMETER LINK-TABLE
STANDARD Mode
1)
FULL
EDIT
Mode
Stereo
2 Way
Stereo
2 Way /
Mono
Sub +
Fullrange
3 Way
+
Fullrange
3 Way
Mono
Sub +
Fullrange
3 Way
Independ.
Sub
+
Fullrange
4 Way
2-In-4
Full
Edit
IN1 / IN2 EQ
YES
YES
N O
Y E S
N O
N O
N O
N O
IN1 / IN2 Delay
Y E S
N O
N O
N O
N O
N O
N O
N O
IN1 / IN2 /
IN1+2 Delay
N O
YES
N O
N O
N O
N O
N O
N O
OUT1 / OUT3
2)
OUT2 / OUT4
Y E S
N O
N O
N O
N O
N O
N O
N O
OUT2 / OUT3
2)
N O
YES
N O
N O
N O
N O
N O
N O
YES: Parameters are linked
NO:
Parameters are not linked
The corresponding x-over frequencies and filter characteristics of the XOVER are additionally linked.
1
) STANDARD Mode can be selected in the DSP 244 Editor software
2
) is true for CHANNEL EQ, COMPRESSOR, LEVEL, XOVER, but not for “Mute”
8.2 DESCRIPTION OF PARAMETERS
The following provides you with a description of all function blocks that can appear in any selected mode
including all available parameters, value ranges, and settings. Additional information about the affect of
each parameter is provided through the corresponding setting example. When entering the EDIT mode,
either the first parameter of the actual program or the parameter that you have edited last are displayed.
MASTER EQ1-5
Both input channels of the DSP 244 employ a 5-Band parametric EQ, each, which provide extreme
flexibility in the programming of full range equalization to match the sound reinforcement system to
different acoustic conditions and venues which in most cases makes the need for post-mix graphic
equalization unnecessary.
Parameter
Settings / Value range
Default
Type
BYPASS, PEQ, LOSLV, HISLV, HIPASS, LOPASS
BYPASS
PEQ
f
Q
Gain
20Hz - 20kHz
0.4 - 20.0
-12dB - +12dB
1.00 kHz
0.7
+0dB
LOSLV
f
Slope
Gain
20Hz - 20kHz
6dB, 12dB
-12dB - +12dB
1.00 kHz
6dB
+0dB
HISLV
f
Slope
Gain
20Hz - 20kHz
6dB, 12dB
-12dB - +12dB
1.00 kHz
6 dB
+0dB
LOPASS
f
Slope
Q
20Hz - 20kHz
6dB, 12dB
0.4 - 2.0 (for 12dB/octave slope only)
1.00 kHz
6 dB
0.7
HIPASS
f
Slope
Q
20Hz - 20kHz
6dB, 12dB
0.4 - 2.0 (for 12dB/octave slope only)
1.00 kHz
6 dB
0.7
