Marantz UD8004 - Manual (Page 33)

Troubl
eshooting
Information
HDMI
Control
Function
Pl
ayback
Connections
Getting Started
Specifi
cations
2
ENGLISH
Setting items Setting contents
DHCP
Set·how·to·perform·network·
confi guration, automatically
or·manually.
Since· the· factory· default·
setting· is· “On”,· you· do· not·
need· to· set· items· such· as·
the· IP· address· if· the· DHCP·
server· of· the· broadband·
router·is·set·to·“Enable”.·
Confi gure a proxy server if
necessary.·
G OnH : Automatically confi gure the network by the DHCP function.
G OffH :·When·connecting·to·a·network,·which·does·not·have·the·DHCP·
function, manually confi gure the following network settings. For the
details of the settings, confi rm with the provider or network administrator.
Use·
·~· ·to·enter·a·value·and·then·press· to fi nalize it.
IP Address (BD-LIVE, Update) : Manually confi gure the IP address for
BD-LIVE·or·Firmware·Update.
IP Address (Control) : This is a confi guration for future extensions.
Usually it is not necessary to confi gure this.
Subnet Mask· :· If· the· xDSL· modem· or· terminal· adaptor· is· directly·
connected to the UD8004, enter the subnet mask notifi ed by the
provider·usually·in·a·document.·Usually,·“255.255.255.0”·is·set.
·
Default Gateway· :· If· the· device· is· connected· to· a· gateway· (router),·
enter·its·IP·address.
Primary DNS·:·Enter·the·primary·DNS.
Secondary DNS·:·Enter·the·secondary·DNS.
•
•
•
•
•
•
Proxy
Set·to·connect·to·the·Internet·
via·a·proxy·server. G OffH Do·not·use·a·proxy·server.
G On (Address)H Set·to·connect·to·the·Internet·via·a·proxy·server.·Use·the·
address·to·specify·the·proxy·server.·Use· ·~· ·to·enter·the·address·
and·then·press· to fi nalize it.
Port :· Use· · ~· · to· enter· a· port· number· and· then· press· · to·
fi nalize it.
G On (Name)H Set·to·connect·to·the·Internet·via·a·proxy·server.·Specify·the·
proxy·server·using·the·domain·name.·Input·the·domain·name·with·the·
virtual·keyboard,·using·
· · · ·and· .
Port :· Use· · ~· · to· enter· a· port· number· and· then· press· · to·
fi nalize it.
•
•
IP Address BD-LIVE, Firmware Update : Displays· IP· address· for· BD-LIVE· or·
Firmware·Update.
Control : Displays·IP·address·for·future·extensions.
MAC Address BD-LIVE, Firmware Update : Displays· MAC· address· for· BD-LIVE· or·
Firmware·Update.
Control : Displays·MAC·address·for·future·extensions.
Set to connect to the Internet.
You can use a disc which offers BD-LIVE function by connecting the unit to the Internet
(vpage 35).
To obtain update support for your UD8004, you can download the latest fi rmware from
our website.
Make a network connect beforehand according to “Connecting to the Network” (vpage
19).
Network Setup
Default settings are underlined.
Remote control operation
buttons
:Displaying·the·menu
·Cancel·the·menu
:Moves·the·cursor·
·(Up/Down/Left/Right)
:Decision·the·setting :Return·to·previous·menu
Setting items Setting contents
Screen Saver
Set·the·screensaver. Off : Do·not·use·the·screensaver.
On : The· screensaver· function· activates· when· stop· or· pause· status·
continues· for· about· three· minutes.· The· screensaver· function· also·
activates during playback of a CD, Super Audio CD or audio fi le when no
operations·are·performed·for·about·three·minutes.
Wallpaper
Set·to·display·the·background·
while·playback·is·stopping. Picture : Displays·the·MARANTZ·logo.
Black : Set·the·background·to·black.
Gray : Set·the·background·to·gray.
Blue : Set·the·background·to·blue.
Still Mode
Set· image· quality· during·
pause. Automatic : Display·automatically·using·“Field”·or·“Frame”·per·the·still·
image·information.
Field : Set·when·there·is·a·blurred·image·when·“Automatic”·image·display·
is·set.·
Frame : Set·to·display·non·moving·images·in·high·resolution.
Slide Show Time
Sets· the· display· time· of·
JPEG fi les. 3 ~ 5 ~ 100sec : This sets the display time per frame of a JPEG fi le during
slideshow·playback.·
Temporary Display
When· the· display· is· set· to·
“Off”·by·the·Dimmer·Control·
(vpage·46)·or·Pure·Direct·
Function· (vpage· 37),· this·
sets·it·to·temporarily·display·
operations·received. Off : Do·not·temporarily·display·operations.
On : Temporarily·display·operations.
Captions
This·setting·output·a·subtitles·
signal· to· a· closed· caption·
decoder·(sold·separately). Off : Do·not·output·the·closed·caption·(subtitle)·signal.
On : Output·the·closed·caption·(subtitle)·signal.
Set display-related items.
Display Setup
Default settings are underlined.
Setup
