KEY PART
NO. NUMBER DESCRIPTION QTY.
1 108075-02 Burner Assembly Base 1
2 108759-01 Pan Burner Assembly 1
3 11165 Screw #10 x 5/8 MD TR BLK 12
4 108763-01 Tube Burner 1
5 104506-19 Pan Burner Orifice #48 (Natural Gas) 1
104506-20 Pan Burner Orifice #56 (Propane/LP Gas) 1
6 108084-02 Pilot Assembly (Natural Gas) 1
108084-03 Pilot Assembly (Propane/LP Gas) 1
7 11102 Screw #8-32 x 3/8 PPH Zinc 2
8 108755-01 Pilot Bracket 1
9 14543 Tube Burner Orifice #51 (Natural Gas) 1
14544 Tube Burner Orifice #59 (Propane/LPGas) 1
10 14528 Brass Elbow Fitting 1
11 14554 Tubing Assembly 1
12 14500 Brass Fitting 1
13 14389 Millivolt Valve (Natural Gas) 1
14390 Millivolt Valve (Propane/LP Gas) 1
14 14253 Flexible Gas Line 1
15 11107 Screw #10-32 x 1/4 PPH Zinc 4
16 26808 Valve Bracket 1
17 26827 Switch Bracket 1
18 14261 Piezo Ignitor 1
PARTS LIST
BURNER ASSEMBLY FOR MODELS
(V)V36N, (V)V36NS, (V)V36NH, (V)V36P,
(V)V36PS, (V)V36PH
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 33 of this manual.
PARTS LIST
Burner Assembly for Models (V)V36N, (V)V36NS, (V)V36NH, (V)V36P, (V)V36PS, (V)V36PH
