PARTS LIST
(V)V36N, (V)V36NS, (V)V36NH, (V)V36P, (V)V36PS, (V)V36PH
PARTS LIST
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 33 of this manual.
REFRACTORY BRICK PANELS
V36NS, V36PS VV36NS, VV36PS V36NH, V36PH VV36NH, VV36PH DESCRIPTION QTY
108081-02 108081-01 108175-02 108175-01 Top Refractory Brick Panel 1
108083-02 108083-01 108177-02 108177-01 Left Refractory Brick Panel 1
108080-02 108080-01 108074-02 108174-01 Rear Refractory Brick Panel 1
108082-02 108082-01 108176-02 108176-01 Right Refractory Brick Panel 1
KEY (V)V36N (V)V36NS (V)V36NH
NO. (V)V36P (V)V36PS (V)V36PH DESCRIPTION QTY.
1 108008-02 108008-02 108008-02 Firebox Assembly 1
2 108009-01 108009-01 108009-01 Face Weldment 1
3 108010-01 108010-01 108010-01 Door Assembly (V Models Only) 1
108010-02 108010-02 108010-02 Door Assembly (VV Models Only) 1
4 108011-01 108011-01 108011-01 Top Panel Louver Assy 1
5 108011-02 108011-02 108011-02 Bottom Panel Louver Assy 1
6 108015-01 108015-01 108015-01 Fireplace Top 1
7 108016-01 108016-01 108016-01 Fireplace Top Insulation 1
8 108017-01 108017-01 108017-01 Fireplace Surround 1
9 109082-01 109082-01 109082-01 Heat Shield 1
10
___
See Below See Below Top Refractory Brick Panel 1
11
___
See Below See Below Left Refractory Brick Panel 1
12
___
See Below See Below Rear Refractory Brick Panel 1
13
___
See Below See Below Right Refractory Brick Panel 1
14 108076-01 108076-01 108076-01 Burner Base Gasket 1
15 108719-01 108719-01 108719-01 Screen Rod 1
16 12105 12105 12105 Screen 2
17 11418 11418 11418 Push-On Nut 2
18 14123 14123 14123 Strain Relief 1
19 21171 21171 21171 Gas Knock-Out Cover 2
20 24353 24353 24353 Handy Box Assembly 1
21 24460 24460 24460 Gas Conduit Assembly 1
22 108760-01 108760-01 108760-01 Burner Assembly (Natural Gas) 1
108760-02 108760-02 108760-02 Burner Assembly (Propane/LP Gas) 1
(See pages 38 and 39)
23 108032-01 108032-01 108032-01 Log Set 1
23-1 109128-01 109128-01 109128-01 Front Log (Log 1) 1
23-2 109129-01 109129-01 109129-01 Rear Log (Log 2) 1
23-3 109130-01 109130-01 109130-01 Crossover Log (Log 3) 1
23-4 109131-01 109131-01 109131-01 Top Log (Log 4) 1
23-5 109132-01 109132-01 109132-01 Left Log (Log 5) 1
23-6 109133-01 109133-01 109133-01 Base Log (Log 6) 1
PARTS AVAILABLE - NOT SHOWN
25487 25487 25487 Lava Rock/Bag Assy 1
27253 27253 27253 Notice Label 1
55240 55240 55240 Vent Label 1
14504 14504 14504 Wall Switch 1
