Denon AVR-3310CI - Manual (Page 9)

ENGLISH
Connections
Set
tin
g
s
Pla
ybac
k
Inf
or
mation
Specifications
Get
ting Star
te
d
Una
vailable F
unctions
Af
ter Upgr
ading
Making Detailed Settings
(Manual Setup)
For details on how to select, set and cancel settings for each menu, see “GUI Menu
Operation” (vpage 26 of GThe original versionH Operating Instructions).
Main remote control
operation buttons
:Displaying the menu
Cancel the menu :Moves the cursor
(Up/Down/Left/Right)
:Confirm the setting :Return to previous menu
Setting items Setting contents
Amp Assign
Sets the signal output to the
speaker connected to the
SURR. BACK/AMP ASSIGN
terminals.
Normal : The surround back channel audio signals are output.
ZONE2 : The ZONE2 audio signals are output.
ZONE3 : The ZONE3 audio signals are output.
ZONE2/3-MONO : The ZONE2 / ZONE3 monaural audio signals are
output.
Front A Bi-Amp : The bi-amp audio signals are output. Set this for bi-amp
playback of the front A speakers.
Front B Bi-Amp : The bi-amp audio signals are output. Set this for bi-amp
playback of the front B speakers.
Front Height : The front height channel audio signals are output.
Front Wide : The front wide channel audio signals are output.
Since “Amp Assign” of AVR-3310CI is set to “ZONE2” by default,
audio is not output from the surround back speakers. When using the
surround back speakers with MAIN ZONE, change the “Amp Assign”
setting to “Normal”.
Perform when setting the speakers manually or when changing settings made in Audyssey Auto Setup.
Making the Speaker Settings (Speaker Setup)
Default settings are underlined.
Setting items Setting contents
Speaker Configuration
Select speaker configuration
and size (bass reproduction
capability).
NOTE
Select “Large” or “Small”
not according to the
physical size of the speaker
but according to the low
frequency reproduction
capabilities based on the
frequency set at “Crossover
Frequency” (vpage 10).
Front : Set the front speaker size.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
When “Subwoofer” is set to “No”, “Front” can automatically set to
“Large”.
When “Front” is set to “Small”, “Center”, “Surround”, “Surround
Back”, “Front Height” and “Front Wide“ can not be set to “Large”.
•
•
•
•
Center : Set the presence and size of the center speaker.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when a center speaker is not connected.
“Large” is not displayed when “Front” is set to “Small”.
•
•
•
Subwoofer : Set the presence of a subwoofer.
Yes : Use a subwoofer.
No : Select when a subwoofer is not connected.
When “Front” is set to “Small”, “Subwoofer” can automatically set
to “Yes”.
•
•
Surround : Set the presence and size of the surround speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the surround speakers are not connected.
When “Surround” is set to “Large”, “Surround Back”, “Front Height”
and “Front Wide“ can be set to “Large”.
When “Surround” is set to “None”, “Surround Back”, “Front Height”
and “Front Wide” can automatically set to “None”.
•
•
•
•
•
When upgrading, contents of “Speaker Setup” are modified.
For setting “Speaker Setup”, make settings by referring to this manual
but not GThe original versionH Operating Instructions.
See overleaf
