ENGLISH
Setting items Setting contents
Speaker Configuration
(Continued)
Surround Back : Set the presence, size and number of surround back
speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the surround back speakers are not connected.
2spkrs : Use two surround back speakers.
1spkr : Use only one surround back speaker. When you select this
setting, connect the surround back speaker to the left (L) channel.
When the “Amp Assign” setting (vpage 8) is other than “Normal”,
you cannot make the “Surround Back” setting.
Even when the Surround Back Speaker setting is other than “None”,
sound may not be emitted from the surround back speaker, depending
on the playback source. In this case, “Surround Parameters” – “Surround
Back” setting other than “OFF” (vpage 12).
•
•
•
•
•
•
•
Front Height : Set the presence and size of the front height speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the front height speakers are not connected.
When the “Amp Assign” setting (vpage 8) is other than “Front
Height”, you cannot make the “Front Height” setting.
•
•
•
Front Wide : Set the presence and size of the front wide speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the front wide speakers are not connected.
When the “Amp Assign” setting (vpage 8) is other than “Front
Wide”, you cannot make the “Front Wide” setting.
•
•
•
Setting items Setting contents
Bass Setting
Settings for subwoofer and
LFE signal range playback.
Subwoofer Mode : Select low range signals to be reproduced by
subwoofer.
LFE : The low range signal of the channel set to “Small” speaker size is
added to the LFE signal output from the subwoofer.
LFE+Main : The low range signal of all channels is added to the LFE
signal output from the subwoofer.
This can be set when “Speaker Configuration” – “Subwoofer” (vpage
8) is set to “Yes”.
Play music or a movie source and select the mode offering the strongest
bass.
Select “LFE+Main” if you want the bass signals to always be produced
from the subwoofer.
•
•
•
•
•
LPF for LFE : Set LFE signal playback range.
80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz / 250Hz •
Distance
Set distance from listening
position to speakers.
Measure beforehand the
distance from the listening
position to each speaker.
Unit : Set the unit of distance.
Feet
Meters •
•
Step : Set the minimum variable width of the distance.
1ft / 0.1ft
0.1m / 0.01m •
•
Front L / Front R / Center / Subwoofer / Surround L / Surround R /
S. Back Lz / S. Back Rz / Front Height L / Front Height R / Front Wide
L / Front Wide R : Select the speaker.
z
: When the “Speaker Configuration” – “Surround Back” setting
(vpage 9) is set to “1spkr”, “S. Back” is displayed.
0.0ft ~ 60.0ft / 0.00m ~ 18.00m : Set the distance.
Speakers set to “None” in “Speaker Configuration” (vpage 8) are not
displayed.
The speakers that can be selected differ depending on the “Amp Assign”
(vpage 8) and “Speaker Configuration” (vpage 8) settings.
Default settings :
Front / Center / Subwoofer / Front Height / Front Wide : 12.0 ft (3.60 m)
Surround / Surround Back : 10.0 ft (3.00 m)
Set the difference in the distance between the speakers to less than 20
feet (6.0 meters).
•
•
•
•
•
Default : Reset all distance settings to factory default.
Yes : Reset to the defaults.
No : Do not reset to the defaults.
When you select “Default” and press ENTER , the “Default Setting?”
prompt is displayed. Select either “Yes” or “No”, and press ENTER .
•
•
Making Detailed Settings (Manual Setup)
Set
tin
g
s
Main remote control
operation buttons
:Displaying the menu
Cancel the menu :Moves the cursor
(Up/Down/Left/Right)
:Confirm the setting :Return to previous menu
