DS6500 ETHERNET MODEL
Local Lonworks Network
Remote Host
Fieldbus
Network
Master Slave 2*** Slave 1***
C-BOX 100**
CAB-610X CAB-610X CAB-60XX
P.S.*
CAB-610X
Encoder****
CAB-610X CAB-610X
CAB-63XX
BTK-6000
Slave 3*** Slave 5*** Slave 4*** PWR-240
CAB-63XX
Fieldbus Small Synchronized Network
*
P.S. (Presence Sensor) connected to External Trigger/PS input.
** C-BOX 100 modified to accept scanner power.
*** The Slave scanners are Master/Slave models, which allow Lonworks network propagation.
**** Encoder connected to IN2/ENC input.
17
