CARE AND MAINTENANCE - 3000 SERIES MODELS
DECK REMOVAL - ELECTRIC CLUTCH - MODEL ZTR 3362:
1. Place cut height lever in lowest cut position.
2. Loosen nut on belt idler shock mount until belt can be removed from electric
clutch pulley on the bottom of the engine.
3. Remove hair pin cotter and washer from one end of deck support cross shaft.
Note location of remaining shim washers used between chassis and mower
deck pan arms. Slide shaft from chassis and mower deck.
4. Remove hair pin cotter and washer from each deck adjustment rod. Carefully
push each link toward the inside of the mower chassis. At this point, deck will
drop down.
5. Carefully raise and support front of chassis. Slide mower deck to either side for
removal. (Reverse procedure to reinstall deck assembly).
6. Refer to illustration on page 24.
Page25
