HUBER+SUHNER MASTERLINE Ultimate Hybrid - Manual (Page 10)

HUBER+SUHNER disclaims any liability resulting from incorrect installation and use, including any damages resulting from the use of
tools and accessories other than the ones recommended herein. Any installation performed by unqualified personnel voids the product
warranty provided by HUBER+SUHNER. All due care and attention must be exercised when performing the installation of these pro-
ducts. For advice concerning the general handling of these products please contact HUBER+SUHNER.
POWER CODING
RRH end Base station end
RRH Wire color Wire color
EU E\\\ US EU US
1 -48V brown black black 1-white 1-black
0V blue grey white 2-white 2-white
ground common drain
2 -48V brown black black 3-white 3-red
0V blue grey white 4-white 4-green
ground common drain
3 -48V brown black black 5-white 5-orange
0V blue grey white 6-white 6-blue
ground common drain
4 -48V brown black black 7-white 7-white/black
0V blue grey white 8-white 8-red/black
ground common drain
5 -48V brown black black 9-white 9-green/black
0V blue grey white 10-white 10-orange/black
ground common drain
6 -48V brown black black 11-white 11-blue/black
0V blue grey white 12-white 12-black/white
ground common drain
INSTALLATION MANUAL
MASTERLINE Ultimate Hybrid
