Dvd playback – Daewoo DF-8100 User Manual

Page 20

PLAYBACK

DVD Playback

Zoom

The Zoom function allows you to magnify the video image and scroll around the enlarged image.

Press [ZOOM] during Play mode to activate the Zoom function.

Each press of the [ZOOM] button changes the Zoom level as follows: X1 (normal size)

➝ X2 ➝ X4 ➝ X1

(normal size)

Use the [œ √…†] buttons to scroll around the zoomed picture.

To resume normal playback, press [ZOOM] repeatedly until the X1 (normal picture) appears.

Repeat
1

To repeat the currently playing chapter, press [REPEAT]. ‘REPEAT CHAPTER’ appears on the TV screen.

To repeat the currently playing title, press [REPEAT] twice. ‘REPEAT TITLE’ appears on the TV screen.

To repeat the whole disc, press [REPEAT] three times. ‘REPEAT DISC’ appears on the TV screen.

You can play in other modes (including Repeat, A-B, Shuffle, or Scan) by pressing [REPEAT] repeatedly.

• The Zoom function may not work on some DVDs.
• The Zoom function does not work in PAUSE mode.

• The Camera Angle icon is displayed on the TV screen when alternate angles are available.

Changing the Audio Language

Press [AUDIO] and then press [AUDIO] repeatedly during playback to hear a different audio language or audio
track.

Subtitles

Press [SUBTITLE] and then press [SUBTITLE] repeatedly during playback to select among all available subtitle
languages.

Camera Angle

If a DVD contains scenes recorded at different camera angles, angle icon displays automatically. You can select
among these angles during playback.
Press [ANGLE] and then press it repeatedly during playback to select the desired angle.
The number of the current angle appears on the TV screen.

• You can repeat a scene that starts when ‘Repeat A-‘ displays on the screen. To mark the end point, press [A-B].

Press [A-B] again to repeat the scene.

DVD Playback

Press [DVD] to set the remote control to operate the DVD deck.

Turn the TV on and select the video input source connected to the DVD Recorder+VCR.

Audio system: Turn the audio system on and select the input source connected to the DVD Recorder+VCR.

Press [OPEN/CLOSE] to open the disc tray.

Load your disc in the tray with the playback side down (label side up).

Press [OPEN/CLOSE] to close the tray.

’READING’ appears on the front panel display, and playback starts automatically. If playback does not start,
press [PLAY (√)]. In some cases, the Disc menu might appear instead.

Playing a DVD+R (+RW)

When a DVD+RW or unfinalized DVD+R is inserted, no title is played automatically but the current TV channel
displays on the screen.
If you want to play a title on the DVD+R (+RW), you must press [MENU] or [PLAY] to display the disc menu.
Select a title to play then press [ENTER].

Playing a DVD

If a Disc menu is displayed

• A Disc menu may be displayed when you load a DVD. Use the [

œ √…†] buttons to select the title/chapter you

want to view, then press [ENTER] to start playback. Press [TITLE] or [MENU] to return to the Disc menu.

• If the Parental Level feature is set and the disc is below the current Parental Level setting, the 4-digit code must

be entered and/or the disc must be authorized; see ‘Set Parental Level‘ on page 29.

• The DVD Recorder+VCR will not play discs with Region codes different from the DVD Recorder+VCR. The Region

code for this DVD Recorder+VCR is 2 (two).

• Unless stated otherwise, all operations described below use the remote control. Some features may also be

available in the Setup menu.

• A disc which is recorded by computer at high speeds (greater than or equal to 2x) may not be recognized.
• A disc which is recorded with unauthorized movie material may not be played.
• A disc which is recorded by other recorder or not recorded correctly may not be recognized or played.

Still Picture and Frame-by-Frame Playback
1

Press [PLAY/PAUSE] during playback. The DVD Recorder+VCR will go into Still mode.

You can back up or advance the picture frame-by-frame by pressing [FF (√√)] repeatedly during Still mode.

Fast Forward/Backward
1

Press [REW (œœ)] or [FF (√√)] during playback. The DVD Recorder+VCR will go into Search mode.

Press [REW] or [FF] to select the desired speed: √√ X2, √√ X4, √√ X8, √√ X16, √√ X32, √ (forward) or
œ, œœ X2, œœ X4, œœ X8, œœ X16, œœ X32 (backward).

• Slow reverse playback is not supported.

Slow Motion

Press [SLOW+] to enter Slow Motion mode. The default speed is 1/2. When you press [SLOW+] repeatedly, the
speed will be set to 1/4, 1/8, and normal speed.

A-B

You can repeat a scene between two points (A and B):

Press [PLAY/PAUSE] play to the start of the desired scene.

Press [A-B] to mark the start point.

Use [FF], [NEXT] to search the end point.

Press [A-B] to mark the end point.

The marked scenes are repeated continuously until you stop the repeat by pressing [A-B] button again.
