EOG52 Features:
1. Rotisserie control knob
2. Grill and Smoker control knobs
3. Drip retrieval tray
4. Interior lights on/off switch
5. Stainless steel grills
6. Halogen cooking lights
7. Infrared rotisserie burner (13,000 BTU)
8. Canopy mounted temperature gauge
9. Side burner control knobs
Lift up work
Surface
Fixed
wheels
Roll out storage
Drawers (2)
Roll out
LP tank
shelf
Gas and
Electrical
Locking
wheel
Lift up work
Surface
Fixed
wheels
Roll out storage
Drawers (2)
Roll out
LP tank
shelf
Gas and
Electrical
Locking
wheel
10. Side burners (2 - 18,000 BTU)
11. Burner grate
Keep warm rack (not shown)
Rotisserie Rod and forks (not shown)
Rotisserie Motor (not shown)
Rotisserie Bracket (not shown)
Removable smoker box (not shown)
Heat control channels (not shown)
Freestanding Cart Model OGC36 Features
Freestanding Cart Model OGC52 Features
Install Liquid Propane (LP) Tank
Slideout LP Tank
Storage Self
Main Tank Valve
Tank Gas
Regulator
Flexible Gas Line
LP Tank
(5 Gal Max.)
Gas Connection at
Right Read Corner
Under Outdoor Grll
Installing the LP Tank
Lighting Liquid Propane Grills
WARNING:
Open canopy before attempting to light the
appliance. Failure to open the canopy could
allow gas to accumulate which could cause
an explosion.
NOTES:
1. Reference your installation instructions
for proper LP gas line connections to
the Dacor regulator and the “Main tank
valve”.
2. Once the tank is properly installed:
• Open the canopy to full open
position.
• Turn on the main tank valve.
• Light one grill burner at a time by
pressing in on the control knob
and turning it counter clockwise
until you hear the clicking ignition
sound. Your burner should ignite
within 4 to 10 seconds.
• Repeat the last step with all control
locations.
Lighting Natural Gas Grills
WARNING:
Open canopy before attempting to light the
appliance. Failure to open the canopy could
allow gas to accumulate which could cause
an explosion.
NOTES:
1. Reference your installation instructions
for proper natural gas line connections
to the Dacor regulator.
2. Once you have confirmed that the
electrical and gas are properly installed,
begin the following processes:
• Open the canopy to full open
position.
• Light one grill burner at a time by
pressing in on the control knob
and turning it counter clockwise
until you hear the clicking ignition
sound. Your burner should ignite
within 4 to 10 seconds.
• Repeat the last step with all control
locations.
