SPECIFICATIONS
Model ZTR 5601
CHASSIS: 11 GA - rectangular tube
BODY: Two piece - made of rotational molded polyethylene. Front body contains
access panels for battery service and engine to mower deck belt removal. Rear
body tilts up to allow service on the entire drive system.
SEAT: Ergonomically designed for operator comfort by use of high density closed cell
foam, contoured back rest and arm rests. Seat is adjustable fore and aft.
MOWER DECK: 1 0 GA stamped steel construction 3 blades combine for
60" cut width Cut height approximately 1 " to 4" via 8
position lift handle
BLADE DRIVE: Electric clutch
DRIVE SYSTEM: Each rear wheel is independently driven by a HydroGear BDU-10L Series 70
hydrostatic transmission. The hydrostatic transmissions, in turn, power a fully
enclosed HydroGear gearbox.
ENGINE: 22HP Kohler Command, 4-Cycle, V-Configuration, Overhead Valve, Air-Cooled,
Gasoline, Horizontal and Vertical Shaft, Aluminum Head, and Crankcase with
Cast Iron Liners, Full Pressure Lubrication/Full Flow Filter, Pulse-type Fuel
Pump, Fixed Jet Carburetor w/Smart-Choke, Electronic Ignition, In-Line Fuel
Filter, Dual Element Air Cleaner.
STARTING SYSTEM: Electric by key switch operation with safety interlocks on parking brake and blade
drive clutch.
TIRES: Front 1 1 X 4 X 5 ribbed tread
Rear 20 X 1 0 X 8 Multi Trac
RECOMMENDED
TIRE PRESSURE:
Front 16-21lbs.
Rear 8-14lbs.
CAPACITIES: Fuel - 4.8 gallons total (dual tanks) , Hydrostat oil tank
- 3 quart with in-line 1 0 micron filter Hydrostat oil
recommendation, refer to page 37 Engine - 2 qts. SAE
10W30 (with filter)
DIMENSIONS: Width 72"
Height 45"
Length 72"
Weight 685 Ibs.
NOTE: Additional information provided in service instructions underthe individual
component.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
