Page 41: Page 40
HARDWARE PART OF CABLE (5) ASSEMBLY
FRAME ASSEMBLY
NOTE:
- WRENCH TIGHTEN HARDWARE.
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
*
V-PREMIER ASSEMBLY
OWNER'S MANUAL
PAGE 40
5
23 11/16" 602
14
5
*
*
*
5
60
5
14
60
PROPER TENSION. RE-TIGHTEN
FINE TUNING:
WARNING - CABLE BOLT MUST BE THREADED
SECURELY TO ENSURE PROPER CONNECTION.
A MINIMUM OF 3/8" WITH JAM NUT TIGHTENED
JAM NUT.
LOOSEN JAM NUT AND THREAD
BOLT IN/OUT TO GIVE THE CABLE
