FRAME ASSEMBLY
NOTE:
- WRENCH TIGHTEN HARDWARE.
- SOME PARTS MAY HAVE BEEN
REMOVED FOR CLARITY.
- INSTALL CABLE AND PULLEYS AT THE
SAME TIME.
OWNER'S MANUAL
V-PREMIER ASSEMBLY
PAGE 32
3
241 3/4" 6142
88
77
14
77
38
98
3
PROPER TENSION. RE-TIGHTEN
JAM NUT.
A MINIMUM OF 3/8" WITH JAM NUT TIGHTENED
BOLT IN/OUT TO GIVE THE CABLE
SECURELY TO ENSURE PROPER CONNECTION.
FINE TUNING:
LOOSEN JAM NUT AND THREAD
WARNING - CABLE BOLT MUST BE THREADED
53
3
JAM BOLT
JAM NUT
