PART LIST CONTINUED
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
OWNER'S MANUAL
PAGE 59
V-EXPRESS ASSEMBLY
ITEM NO. PART NUMBER DESCRIPTION QTY
71 026-01P1425 BACKING PAD SUPPORT 1
72 026-01P1429 GUSSET PLATE 2
73 026-01P1689 DOUBLE PULLEY MOUNT PLATE 2
76 026-01PL0125-125 E-Z GLIDE PLASTIC SLEEVE 4
77 026-01PL0134 GUIDE ROD BUSHING 2
78 026-01PL0235-27 GRIP: Ø1.19" OPEN END FOAM GRIP 2
79 026-01PL0269 CAST WEIGHT BUSHING 28
80 026-01PL0369 WEIGHT STAND OFF 2
81 026-01PL0371 DELRIN BUSHING 1
82 026-01PL0381 BUMPER, HALF ROUND, DUAL STEM 1
83 026-01PL0382 DUAL STEM PLUG BUMPER - BLACK 1
84 026-01PL2003 HANDLE BRACKET 2
85 026-01W0139 21 HOLE STEM 1
86 026-01W0142 10 LBS. INTERMEDIATE RADIAL LOC WEIGHT PLATE 14
87 026-STD-06-0254 ROLLER BUSHING, 1" 8
88 026-STD-SWTOP9 CAST RADIAL TOP WEIGHT 1
89 030-0303006 ROLL PIN Ø.44" O.D. X 3.00" LG. (WZ) 1
90 013-0102020 3/8" SPLIT LOCK WASHER (WZ) 4
91 013-0102022 3/8" INTERNAL LOCK WASHER 8
92 013-0102023 1/4" INTERNAL LOCK WASHER 2
93 013-0102028 3/8" CURVED WASHER (WZ) 6
94 013-0102003 1/2" X 27mm SAE FLAT WASHER (WZ) 12
95 013-0402007 3/8" X 22mm FLAT WASHER (WZ) 78
96 013-0302008 5/16" SAE FLAT WASHER (WZ) 4
97 013-0002003 1/4" X 16mm SAE FLAT WASHER (WZ) 3
98 011-0101041 3/8"-16UNC X .75" BHCS (WZ) 8
99 011-0101025 1/4"-20UNC X 1.00" BHCB (WZ) 2
100 011-0002033 3/8"-16UNC X 1.25" FHCS (WZ) 4
101 011-0107014 1/2"-13UNC X 5.00" HHB (WZ) 1
102 011-0407047 1/2"-13UNC X 4.00" HHB (WZ) 1
103 011-0407024 1/2"-13UNC X 2.75" HHB (WZ) 2
104 011-0307060 1/2"-13UNC X 6.00" HHB (WZ) 1
105 011-0107022 3/8"-16UNC X 5.00" HHB (WZ) 15
