Hoist Fitness V-EXPRESS - Manual (Page 58)

PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
PAGE 57
OWNER'S MANUAL
V-EXPRESS ASSEMBLY
ITEM NO. PART NUMBER DESCRIPTION QTY
1 010-01C0280T LEG EXTENSION CABLE ASSEMBLY 1
2 010-01C0611T FLOATING PULLEY CABLE ASSEMBLY 1
3 010-01C0612T ANCHOR CABLE ASSEMBLY 1
4 010-01C0613T PULLDOWN CABLE ASSEMBLY 1
5 022-01PD0106-A SEAT PAD ASSEMBLY 1
6 022-01PD2024-A PAD W/WRAPPED EDGE 1
7 022-01PDR008 ROLLER PAD 4.00" X 7.00" LG. 4
8 026-01X0185 PULL-PIN ASSEMBLY 2
9 026-01X1118 ALUMINUM CURL BAR ASSEMBLY 1
10 026-01X1119 ALUMINUM LAT BAR ASSEMBLY 1
11 026-01X5322 PRESS ARM MOUNT ASSEMBLY 1
12 026-01X1404 BAR MOUNT ASSEMBLY 1
13 026-01X1411 U-JOINT ASSEMBLY 2
14 026-01X1414 ADJ. FLOATING PULLEY HOUSING ASSEMBLY 2
15 026-01X1419 FRAME BASE ASSEMBLY 1
16 026-01X1421 LEG EXTENSION ARM ASSEMBLY 1
17 026-01X1425 ROLLER MOUNT ASSEMBLY 2
18 026-01P6394 CABLE ANCHOR PLATE 1
19 026-01X1619 PULL-PIN ASSEMBLY 1
20 026-01X1640 SEAT ADJUST ASSEMBLY 1
21 026-01X1641 ADJUSTABLE ROLLER ASSEMBLY 1
22 026-01X2039 RADIAL CAST WT.SELECTOR PIN ASSEMBLY 1
23 026-01X2061 LEFT HANDLE 1
24 026-01X2062 RIGHT HANDLE 1
25 026-01X2063 PRESS ARM ASSEMBLY 1
26 026-01X2065 RIGHT ARTICULATING ARM 1
27 026-01X2066 LEFT ARTICULATING ARM 1
28 026-01X4057 STRAP HANDLE WITH (3) D-RINGS (LOWER) ASSEMBLY 2
29 026-01X5007 ACCESSORY RACK ASSEMBLY 1
30 026-01X5012 SHIELD MOUNT - TOP ASSEMBLY 1
31 026-01P6119 BACKING PLATE 1
32 026-01X5236 MAIN BASE SUPPORT 1
33 026-01X5237 TOP MAIN FRAME 1
34 026-01X5276 FRONT UPRIGHT 1
35 010-0008001 LANYARD COIL 1
