ITEM NO.
PART NUMBER
DESCRIPTION
QTY
71
011-0407016
1/2"-13UNC X 3.00" HHB (WZ)
2
72
011-0407000
1/2"-13UNC X 3.50" HHB (WZ)
2
73
011-0407047
1/2"-13UNC X 4.00" HHB (WZ)
2
74
011-0107014
1/2"-13UNC X 5.00" HHB (WZ)
4
75
011-0107036
1/2"-13UNC X 5.75" HHB (WZ)
2
76
011-0107066
1/2"-13UNC X 7.50" HHB (WZ)
1
77
012-0104008
3/8"-16 UNC THIN NYLOCK NUT (WZ)
14
78
012-0304011
1/2"-13 UNC THIN NYLOCK NUT (WZ)
22
79
021-0003008
DECAL COMMERCIAL MAINTENANCE 1.50" X 6.69"
1
80
021-0003113
DECAL PINCH POINT 1.63" X 3.25" (VERTICAL)
1
81
021-0003135
DECAL WARNING 1.50" X 6.69"
1
82
021-0003230
DECAL HOIST 1.63" X 5.93"
1
83
021-0003320
DECAL 800 LB. WEIGHT RATING (1.63" X 1.63")
1
84
021-0003334
DECAL HOIST 3.90" X 14.25"
2
85
021-0003341
DECAL PINCH POINT 1.07" X 2.13" (HORIZONTAL)
2
86
021-0003405
DECAL ROX
2
87
021-0003725
DECAL Ø 1.44" RED PIVOT POINT
2
88
021-0004032
DECAL ADJUST 1-7 VERTICAL TXT.
1
89
021-0018022
DECAL HOISTFITNESS.COM LOGO
1
90
021-0003691
RPL-5102 PREACHER CURL PLACARD
1
91
SERIAL # DECAL
DECAL HOIST SERIAL # 1.63" X 2.63"
1
OWNER'S MANUAL
PAGE 39
RPL-5102 ASSEMBLY
PART LIST CONTINUED
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
