Page 38
ITEM NO.
PART NUMBER
DESCRIPTION
QTY
1
026-01PL2236
TOP CAP W/INSERTS
1
2
026-01X3294
REAR UPRIGHT LEFT ASSEMBLY
1
3
026-01X3377
REAR UPRIGHT RIGHT ASSEMBLY
1
4
026-01X2026
ADJUSTABLE PULLEY MOUNT
1
5
026-01X2402
FOOT PLATE ASSEMBLY
2
6
026-01X2849
RACHET PULL-PIN ASSEMBLY
1
7
026-01X2975
FOOT PLATE MOUNT ASSEMBLY
2
8
026-01X3284
LIFT ARM
1
9
026-01X3287
SHAFT, LIFT-ARM ASSEMBLY
1
10
026-01X3305
WEIGHT HORN ASSEMBLY
2
11
026-01X3319
BASE FRAME ASSEMBLY
1
12
026-01X3320
USER SUPPORT FRAME
1
13
026-01X3321
FLOATING LINK
1
14
026-01X3323
HANDLE ASSEMBLY
2
15
026-01X3324
CURL ARM LEFT
1
16
026-01X3325
USER SUPPORT FRAME, UPPER
1
17
026-01X3356
SEAT ADJUSTER ASSEMBLY
1
18
026-01X3415
CENTER UPRIGHT
1
19
026-01X3419
CURL ARM RIGHT
1
20
010-01C0611
CABLE ASSEMBLY: RPL BICEP 133.25" LG
1
21
022-01PD2054-A
SEAT PAD ASSEMBLY
1
22
022-01PD2097-A
ARM PAD ASSEMBLY
1
23
011-0411001
SET SCREW: 1/4"-28 X .25" LG. (SS)
4
24
014-0009007
BEARING: FLANGED Ø2.00" O.D. X Ø1.00" I.D.
10
25
014-0012010
BEARING: FLANGED BEARING Ø2.50" O.D. X Ø1.39" I.D.
2
26
014-0012013
BEARING: BALL BEARING Ø2.44 O.D. X Ø1.18" I.D.
4
27
014-0019005-2
SPLIT COLLAR: 1.00" I.D. X 20mmT NON-THREADED
1
28
016-0001003
END CAP 1.50" X 2.50" (BLACK)
1
29
018-0001003
CABLE PULLEY:
4.50"
3
30
018-0002012
WIDE GROOVE PULLEY
4.50"
2
31
019-0001001
PLUG BUMPER
4
32
026-01F0251
BRACKET PLATE: 2 HOLES 7.00" X 2.75"
1
33
026-01F0307
FLANGE: 2 HOLES 6.25" X 2.50"
1
34
026-01M0199
QUICK RELEASE CABLE LOCK Ø 1/4"
2
35
026-01M0660
SHAFT Ø1.00" O.D. X Ø .52" I.D. X 4.69" LG.
2
OWNER'S MANUAL
PAGE 37
RPL-5102 ASSEMBLY
PART LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
