Machine adjustment, Owner's manual, Rpl-5102 assembly – Hoist Fitness RPL-5102 User Manual
Page 32: Page 31
20
20
78
4
ADJUS
T
TO ADJUST TENSION OF CABLE (20).
RPL-5102 ASSEMBLY
STEP 1:
NOTE:
THEN ADJUST POSITION OF PULLEY (4)
STEP 2:
HAND TIGHTENED HARDWARE.
- SOME PARTS MAY HAVE BEEN
- BE SURE BUMPER (43) STAYS IN
MACHINE ADJUSTMENT
WRENCH TIGHTEN NUTS (77 & 78).
- ONCE DESIRED TENSION IS REACHED,
REMOVED FOR CLARITY.
OWNER'S MANUAL
CONTACT WITH FRAME (11),
- WRENCH TIGHTEN ALL PREVIOUSLY
PAGE 31
- LOOSEN NUTS (77 & 78).
43
11
BE SURE BUMPER (43) STAYS IN
CONTACT WITH FRAME (11).
77
4
