ITEM NO.
PART NUMBER
DESCRIPTION
QTY
36
026-01M0936
ALUMINIUM RING:
1.00" I.D.
2
37
026-01M0937
END CAP: ALUMINUM
1.0" I.D.
2
38
026-01M1185
WEIGHT HORN SHAFT 15.00"LG.
4
39
026-01M2043
BOLT STAND-OFF
2
40
026-01M2320
END CAP: DOMED
2.25" O.D.
2
41
026-01M2348
SHAFT
1.375" X 6.35" LG.
1
42
026-01M2356
END CAP: DOMED
2.75" O.D.
2
43
026-01PL2246
DUAL HOLE BUMPER 2.05" THICK
1
44
026-01PL0125
E-Z GLIDE PLASTIC SLEEVE
2
45
026-01PL0206-13
.938" X 10.50" LG. OPEN END GRIP
2
46
026-01PL0264
WEIGHT HORN RUBBER DONUT
2
47
026-01PL2122
OVAL-SHAPED RUBBER FOOT
1
48
026-01PL2131
D-SHAPED RUBBER FOOT
2
49
026-01PL2140
BLACK NYLON THREADED CAP
2
50
026-01PL2313
WEIGHT HORN RUBBER DONUT W/ 3.75 COPE
4
51
013-0002003
1/4" X 16mm SAE FLAT WASHER (WZ)
2
52
013-0302008
5/16" SAE FLAT WASHER (WZ)
6
53
013-0402007
3/8" X 22mm FLAT WASHER (WZ)
34
54
013-0102003
1/2" X 27mm SAE FLAT WASHER (WZ)
35
55
013-0102023
1/4" INTERNAL LOCK WASHER
2
56
013-0408001
3/8" INTERNAL LOCK WASHER (SS)
2
57
013-0102022
3/8" INTERNAL LOCK WASHER
6
58
011-0007097
1/4"-20UNC X .75" SHCS (BZ)
2
59
011-0101122
1/4"-20UNC X 2.50" BHCS (WZ) w/ NYLON PATCH
2
60
011-0107011
5/16"-18UNC X 1.25" HHB (WZ)
6
61
011-0311013
3/8-16UNC X .75" SQUARE HEAD (WZ)
1
62
011-0101063
3/8"-16UNC X 1.00" SHCS (WZ)
2
63
011-0101026
3/8"-16UNC X 1.00" BHCS (WZ)
8
64
011-0407022
3/8"-16UNC X 1.00" HHB (WZ)
1
65
011-0401002
3/8"-16UNC X 1.25" BHCS (SS)
2
66
011-0101034
3/8"-16UNC X 1.25" BHCS (WZ)
2
67
011-0407058
3/8"-16UNC X 2.00" HHB (WZ)
3
68
011-0107026
3/8"-16UNC X 2.25" HHB (WZ)
2
69
011-0101016
3/8"-16UNC X 2.75" BHCS (WZ)
4
70
011-0407042
1/2"-13UNC X 1.00" HHB (WZ)
4
OWNER'S MANUAL
PAGE 38
RPL-5102 ASSEMBLY
PART LIST CONTINUED
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
