Page 7: Rbu parts list
Propeller Upblast Roof Fans
7
7
Propeller Upblast Roof Fans
6
Parts List
1. Fan Panel
2.
Propeller
3. Drive Frame Channel (2)
4. Motor Plate
5.
Motor
6. Motor Pulley
7. Shaft Pulley
8. Fan Shaft
9. Bearings (2)
10. Belt
11. Motor Cover (RBUMO only)
RDU Parts List
1
2
5
4
3
RBUMO Parts List
2
5
8
7
10
3
9
11
4
1
RBU Parts List
1
2
5
8
6
7
10
4
3
9
®
