Page 7
Belt Drive Duct Fan
7
®
REPLACEMENT NEOPRENE ISOLATOR(S)
MODEL
FAN SIZE
BDF
80-100
120-150
180-200
BASE MOUNT
R-1 GREEN
R-2 BLACK
R-2 RED
HANGING
40DUR BLACK
50DUR BLACK
50DUR BLACK
REPLACEMENT SPRING ISOLATOR(S)
MODEL
FAN SIZE
BDF
80-90
100-200
150-180
200
BASE MOUNT
FDS-1-70 GREEN
FDS 1-120 GRAY
FDS-1-220 BROWN
FDS-1-370 ORANGE
HANGING
SH-1-70 GREEN
SH-1-125 GRAY
SH-1-245 BROWN
SH-1-370 ORANGE
STANDING SUPPORT ISOLATOR
HANGING SUPPORT ISOLATOR
No. Qty.
Description
BDF-80 thru 150
BDF-180 thru 200
No. Qty.
Description
BDF-80 thru 150
BDF-180 thru 200
1
8
Cadmium plated
hex head bolts
3/8 in. - 16 x 1 in.
3/8 in. - 16 x 1-1/4 in.
1
8
Cadmium plated
hex head bolts
3/8 in. - 16 x 1 in.
3/8 in. - 16 x 1-1/4 in.
2
8
Cadmium plated
hex nuts
3/8 in. - 16
3/8 in. - 16
2
16
Cadmium plated
hex nuts
3/8 in. - 16
3/8 in. - 16
3
4
Cadmium plated
hex head bolts
5/16 in. - 18 x 1 in.
3/8 in. - 16 x 1 in.
3
4
Std. mount
bracket with one
1/4 in. hole
3/16 in.
1/4 in.
4
8
Std. mount
bracket with two
7/16 in. holes
3/16 in.
1/4 in.
4
4
Std. mount
bracket with two
7/16 in. holes
3/16 in.
1/4 in.
5
20
Cadmium plated
washer
7/8 in. O.D. x
3/8 in. I.D. x 1/16 in.
7/8 in. O.D. x
3/8 in I.D. x 1/16 in.
5
24
Cadmium plated
washer
7/8 in. O.D. x
3/8 in. I.D. x 1/16 in.
7/8 in. O.D. x
3/8 in. I.D. x 1/16 in.
6
12
Cadmium plated
lock washer
3/8 in.
3/8 in.
6
12
Cadmium plated
lock washer
3/8 in.
3/8 in.
7
4
Cadmium plated
washer
1-3/8 in. O.D. x
9/16 in. I.D. x 3/32 in.
1-3/8 in. O.D. x
9/16 in. I.D. x 3/32 in.
7
12
Cadmium plated
washer
1-3/8 in. O.D. x
9/16 in. I.D. x 3/32 in.
1-3/8 in. O.D. x
9/16 in. I.D. x 3/32 in.
8
4
Neoprene or
Spring Isolator
Reference appropriate table below for
replacement Isolator(s)
8
4
Neoprene or
Spring Isolator
Reference appropriate table below for
replacement Isolator(s)
1
1
2
2
3
4
4
5
5
5
5
5
6
6
6
7
8
Unit side panel
Base fastener
(by installer)
1
1
2
2
2
2
3
4
5
5
5
5
5
5
6
6
6
7
7
7
8
Unit side panel
Note: Top bracket
is reversible for
mounting unit 90°
from indicated.
(SQ and BSQ only)
Isolator Parts List
