Featur
es & Options
10
2. The fault code will be displayed. Use the up and down arrows to scroll through the
faults. Resolve the issue with the action listed in Description of Fault Codes chart and
the Fault screen will disappear. To remove a tamper fault, select CLEAR.
IMPORTANT: See the Description of Fault Codes for more details regarding a fault and
resolution actions. All faults, except a tamper, will automatically be cleared when the issue
has been resolved. An event will be recorded in the event log indicating the date and time
that the event occurred and was resolved.
NOTE: A tamper fault will not be automatically cleared. After the device has been
inspected, checked for damage, and the cover closed, the fault will need to be cleared.
See Clearing a Fault. This process was designed to create awareness of the tamper
with the master user and require verification that the problem has been resolved.
CLEARING A FAULT
To clear any fault other than a tamper fault, correct the condition at the sensor. For
example: replace the battery, relocate to an area with a better signal, etc.
To Clear a Tamper Fault:
IMPORTANT: Before clearing a tamper fault, be sure that the issue has been resolved.
Only the master user can clear tamper faults.
1. When the Fault Code screen is displayed; select CLEAR.
2. Use the keypad to enter the master code.
3. Select OK.
DESCRIPTION OF FAULT CODES
NOTE: See the Troubleshooting Guide for more detailed information.
Fault Code Fault Display Description Action
Power Primary Power No power to Check power supply
Lost Base Base Unit
DevPower Primary Power Lost No battery power Change battery, reset
Device # in device
BaseLowBatt Base Base Unit Plug in power supply
Low Battery battery low to recharge battery
DevLowBatt Low Battery Device battery Change battery, reset
Device # low
WeakSig Weak Signal Transmission signal Check for interference;
Device # from device is weak move device
Unsecured Unsecured Device has Check for intrusion;
Device # been tripped re-secure device
NoCheckIn No Check In Device check-in Check for interference;
Device # messages have not move device
been received
DESCRIPTION OF FAULT CODES
NOTE: The battery will take up to 24 hours to charge completely. To avoid draining
the battery, do not use an outlet that is controlled by a wall switch. The battery is
designed to be a back-up source of power for up to 8 hours. If the monitoring service
has been activated, the Base Unit will send a low battery message to the monitoring
servce approximately 1 hour before the battery is drained. If power is not restored
within that remaining hour, the Base Unit will disarm and shut down.
IMPORTANT: After power has been restored, the Base Unit will not be armed.
System Settings
The systems settings menu allows for changes in user codes, wireless devices, automatic
arming, delays and account information.
• Wireless Device Maintenance • Clear Settings
• Change Master Code • Auto Arm ON/OFF
• User Code Maintenance • Auto Arm Time Set
• Set Console Devices • Review Account
• Set Delay/Instant • Choose Language
WIRELESS DEVICE MAINTENANCE
After the initial setup, a device such as a sensor or Key Chain Remote can be added,
edited or removed.
• Adding or Replacing a Device
• Editing a Device
• Removing a Device
1. Start at the main screen.
2. Select MENU or press MAIN MENU on the keypad.
3. Using the keypad, enter the master code.
FEATURES & OPTIONS
Fault Code Fault Display Description Action
Tamper Tamper Device has been Close device or
opened or damaged replace if damaged
BaseBadBatt Bad Battery Base Unit battery has Needs to be repaired
Base dropped below the at D E WALT authorized
voltage limit service center
CellRadio Cell Radio Cellular radio Move Base Unit to
Fault signal is lost a location where
or scrambled CELL light is solid;
call Customer Service
if problem persists
Receiver Receiver Fault 2-way transmission Call customer service
Device # of device is lost to test system for issues
NetControl Base Network Base RF processor Internal check; will clear
Control communications itself; call Customer Service
if problem persists
DESCRIPTION OF FAULT CODES cont.
