20
Wall bracket op-
tion
Preparations for
security lock The security lock is not contained in the
scope of supply.
A security lock can only be attached
-
to the groove on the housing as shown
- to the groove on the housing that is ex-
actly opposite
- using spacer M8 DIN 125 or DIN 134,
located as shown
Installation
The space requirement measurements in mm illustrated below are given to ensure that
there is easy access to the plug connections:
1
1
"click"
"click"
~ 120 mm
130 mm
NOTE! If the charger is installed in a switch cabinet (or a similar separate area),
then forced-air ventilation must be provided to ensure adequate heat dissipation.
There must be a clearance of 10 cm all around the charger.
