PCI Express Settings
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
PCI Express Device Register Settings
No Snoop [Enabled]
Maximum Payload [Auto]
Maximum Read Request [Auto]
PCI-E1_16X Slot ASPM Support [Disabled]
PCI-E1_1X Slot ASPM Support [Disabled]
PCI-E2_1X Slot ASPM Support [Disabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Enables or Disables PCI
Express Device No Snoop option.
Advanced
► No Snoop
This item is used to enables or disables PCI express device no snoop option.
► Maximum Payload
This item is used to set maximum payload of PCI Express device or allow system BIOS to
select the value.
► Maximum Read Request
This item is used to set maximum read request size of PCI Express device or allow system
BIOS to select the value.
► PCI-E1_16X Slot ASPM Support/PCI-E1_1X Slot ASPM Support/PCI-E2_1X Slot ASPM Sup-
port
This item is used to enable or disable the PCI Express Slot Active State Power Management
settings.
