Integrated Peripherals

► OnBoard PCI IDE Controller

This item is used to enable or disable the IED controller.

► OnChip SATA Channel

[Disabled] : Disable SATA controller.
[Enabled] : Enable SATA controller.

► OnChip SATA Type

This item is used to set the operating mode of your SATA ports.
Options : [Native IDE]; [RAID]; [Legacy IDE]; [IDE -> AHCI].
[Native IDE] - This configures the SATA ports to support native IDE mode.
[RAID] - When you enable RAID, it means all your SATA drives must also support AHCI.
[Legacy IDE] - This configures the SATA ports to support legacy IDE mode which is running
for old Windows system .
[IDE -> AHCI] - The Advanced Host Controller Interface (AHCI) specification describes the
register
level interface for a Host Controller for Serial ATA. The specification includes a description of
the hardware/software interface between system software and the host controller hardware.
AHCI provides more advanced features including SATA features, but some SATA drives may
not support AHCI, unless they are labeled with AHCI support in its specification.
If your motherboard supporting AHCI, and you have a SATA device, which also supports AHCI,
then you can select IDE option to have fair performance (only PATA, SATA level), or you can
select AHCI to get its best performance.

► OnBoard Devices / USB Configuration / SuperIO Configuration

Press to go to relative submenu.

Integrated Peripherals

OnBoard PCI IDE Controller Help Item

OnChip SATA Channel [Enabled]

OnChip SATA Type

[Native IDE] DISABLED: disables the

► OnBoard Devices

[Press Enter]

integrated IDE

► USB Configuration

[Press Enter]

Controller .

► SuperIO Configuration

[Press Enter]

PRIMARY : enableds only

the Primary IDE

Controller.

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help

F9:Optimized Defaults

[Enabled]
