Formax Cut-True 15M - Manual (Page 9)

A
5. Raise the blade lever arm to its top position.
6. Remove the screw on the clamp handwheel and
remove the wheel.
7. Remove the handgrip from the blade lever arm by
twisting the handgrip toward the left and unscrewing it.
7. Remove four screws on the blade housing cover.
9. Move the blade lever arm to a 75+ angle and slide the
blade housing cover off.
After steps 1-9, the cutter should look like this.
2. Lower the blade lever arm to horizontal position.
3. Remove the four screws on the front safety cover,
then remove the cover itself.
4. Remove the right blade screw (A).
6
10. Raise the blade lever arm to upright position.
11. Remove the far left blade screw.
12. Remove the screws to the left and right of center.
NOTE: Do Not remove the center screw.
13. Attach the Blade Change Safety Tool to the blade,
screwing in the handles to the holes to the left and
right of center. Tighten securely.
Center screw
14. Remove the center screw. The blade and safety tool
should remain in place.
