. Ensure correct position of installation. The name plate N must always be on top (UNA 38).
. Observe direction of flow. The arrow indicating the flow direction is on the trap body.
3. Consider space required for opening trap. When the trap is installed, a minimum space of at least
150 mm (UNA 39) or 310 mm (UNA 38) is required for removing the cover M.
4. Remove plastic plugs. They are only used as transit protection.
5. Clean the socket-weld ends.
6. Arc-weld the trap
only manually (welding process and 4 in accordance with ISO 4063).
Design with socket-weld ends
. Ensure correct position of installation. The name plate N must always be on top (UNA 38).
. Observe direction of flow. The arrow indicating the flow direction is on the trap body.
3. Consider space required for opening trap. When the trap is installed, a minimum space of at least
150 mm (UNA 39) or 310 mm (UNA 38) is required for removing the cover M.
4. Remove plastic plugs. They are only used as transit protection.
5. Clean the seating surfaces of both flanges.
6. Install the steam trap.
Design with flanges
. Ensure correct position of installation. The name plate N must always be on top (UNA 38).
. Observe direction of flow. The arrow indicating the flow direction is on the trap body.
3. Consider space required for opening trap. When the trap is installed, a minimum space of at least
150 mm (UNA 39) or 310 mm (UNA 38) is required for removing the cover M.
4. Remove plastic plugs. They are only used as transit protection.
5. Clean the butt-weld ends.
6. Arc-weld the trap manually (welding process and 4 in accordance with ISO 4063) or use
gas-welding (welding process 3 in accordance with ISO 4063).
Design with butt-weld ends
Installation
Depending on its body design, the float trap UNA 38 can be installed in horizontal or vertical pipes with
downward flow.
UNA 38
Attention
n Only qualified welders certified e.g. according to EN 87- may weld the steam trap
into pressurized lines.
The float trap UNA 39 can be installed in vertical pipes with downward flow.
UNA 39
